Problems To Be Aware Of When Using The Pittsburgh Lock Former

Now many manufacturers are using the pittsburgh lock former machine, so what needs to be paid attention to when using the pittsburgh lock former machine?
Let's just say eight.

1. Start the machine of the pressing machine to make a number of cycles, and make sure that under normal circumstances, the cutting of different thickness plates shall be made from thin to thick.
Make sure the user is familiar with the pittsburgh lock former machine performance.
2. The gap between different blades must be adjusted when different plates are thick.
If the corresponding blade gap is not adjusted, the blade durability is affected.
3. Open the pressure gauge switch during the cutting process, observe the oil pressure value, and the pressure should be less than 20MPa when cutting 12mm plate.
This remote pressure regulating valve No9, the pressure of the delivery time is set 20-22mpa, the user must comply with this regulation, not to cut the material surface to increase the pressure, resulting in machine damage.
4. Sound balance during operation.
If there is noise in the bite machine, stop check.
5. The oil tank increases the temperature when the bite machine operates <60 degrees and shuts off rest.
6. The blade of the blade should be kept sharp, if the blade is blunt or disintegrated, it should be replaced in time.
7. When the shear plate is cut, the press should be firmly pressed on the plate, and it is not allowed to continue to cut when the pressure is not tight.
8. There is a hydraulic installation, except for the other hydraulic valves.

Pittsburgh Lock Former
